Laboratory Information

Laboratories along Major equipments / facilities

S.No. Name of the laboratory Major Equipments
1. Testing of materials
  1. Universal Testing Machine
  2. Compression Testing Machine
  3. Concrete Mixer
  4. Aggregate Impact Tester
2. Surveying
  1. Total Station
  2. 5Sec Electronic Theodolite
  3. 10Sec Transit Vernier Theodolite
  4. 1 Sec Theodolite
3. Engineering geology
  • Mineral Specimen
  • Rock Specimen
  • Structural Geology models
  • Hardness collection: set of 9 minerals
  • Lustre& cleavage: set of 10 mineral
  • Fracture collection : set of 6 minerals
4. Engineering mechanics
  • Parallel force Apparatus
  • space force apparatus
  • Belt friction apparatus with combined coil and flat belt friction apparatus
  • Polygon of force apparatus
  • Slotted weight hanger
5. Geotechnical engineering
  • Hot air oven
  • Direct shear Test apparatus
  • Triaxial shear test apparatus
  • Unconfined Compression Test Apparatus
  • Soil Permeability Apparatus
6. Environmental engineering
  • Jar Test Apparatus
  • U. V. Visible Spectrometer
  • RQ-126/D medium Duty stirrer with PMDC Motor
  • Respirable Dust sampler Amp. 460
  • Flame photometer Model 306
  • Cod Reflux apparatus
7. Fluid mechanics
  • Pelton Wheel Turbine
  • Francis Turbine
  • Centrifugal Pump
  • Flume (Tilting)
  • Wind Tunnel
  • Impact of JET Apparatus
8. Computer laboratory
  • computer-Intel I3 processor DVD R/W, 500GB HDD, kingstonDDr-III, 4GB RAM,ATX cabinatesamsung Monitor, etc
  • Lenovo branded computer, Intel core I5 processor, 3RD generation, intel original motherboard, 4GB DDR-III, 500GB HDSATA, DVD R/W, 18.5" LED monitor,OS DOS
  • HP 1020 leserjet Printer
9 Transportation
  • Aggregate crushing Test Apparatus
  • Aggregate Impact Tester
  • Los Angeles Abrasion Testing Machine
  • Ductility Testing Machine : IS : 1208
  • Centrifuge Extractor, Electrically operated. .
  • Marshall Stability and Compaction ASTM D 1559.

Experiment on beam support reaction in Engineering Mechanics Laboratory

Experiment in progress using Total Station

Universal Testing Machine at Concrete Technology Laboratory

Experiment on Initial and Final Setting Time of Concrete

Students in AutoCAD Lab of the Department

Experimental Setup in Environmental Laboratory

Project work in Fluid Mechanics Laboratory

Experiment Performing in Transportation Laboratory

Teaching session Progress in Surveying Laboratory

Experiment in Material and Testing Laboratory
